Producer | BTS Engineering |
Pump capacity, cu.m/hour | 150 |
Feed height, m | 47 |
Power capacity, kW | 30 |
Material | cast iron |
Input pipe diameter | 125 |
Output pipe diameter | 100 |
Rate of turn, rpm | 3 000 |
Protection | IP55 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | No |
Max.temperature, C | 120 |
Seal | Mechanical Seal, Carbon-SiC-NBR |
Impeller material | cast iron |
Nom.flow rate, m3/h | 150 |
Nom.head, m | 47 |
Housing material | Сast iron |
Serial number of the pump | BST |
Country of Origin | China |
PumpType | console |
Drive Type | electric |
Installation Type | horizontal |
Type of configuration | with engine |
Warranty, months | 12 |
Application | coolant, detergents, process fluids, heating systems, non-corrosive liquids, tosol, antifreeze, glycerol, water, increasing pressure, brake fluids |
Analogue for | Ebara 3D, Speroni CFM, Speroni MEM, Speroni CS, Pedrollo HF, CALPEDA NM |
Weight, kg | 220 |
Length of transport packing, cm | 92 |
Width of transport packing, cm | 43 |
Height of transport packing, cm | 66 |
Height of transport volume, cbm | 0,261 |
