Rated power, kW | 1 |
Rated voltage, V | 48V, 24V, 12V |
Maximum power, kW | 1,1 |
Blades Length, m | 1,3 |
Wheel Diameter, m | 0,52 |
Blades Quantity | 2 |
Start Up Speed, m/s | 1,5 |
Rated Speed, m/s | 12 |
Cut-in Speed, m/s | 4 |
Survival Speed, m/s | 45 |
Blades Material | glass fibre |
Wind Generator Type | Permanent magnet, magnetic levitation and coreless disc type generator |
Working environment humidness | ≤90% |
Altitude | ≤4500 |
Install Height, m | 6~12 |
Overload Protection | Electromagnetic Brake |
Producer | R&X Energy |
Protection | IP54 |
Noise level ,dB | 30 |
Packaging | 17x17x132cm; 55x35x35cm |
Operating temperature | -40°C +40°C |
Series | Spiral Type |
Country of Origin | China |
Gross weight, kg | 28 |
Rated power, kW | 1 |
Rated voltage, V | 48V, 24V, 12V |
Maximum power, kW | 1,1 |
Blades Length, m | 1,3 |
Wheel Diameter, m | 0,52 |
Blades Quantity | 2 |
Start Up Speed, m/s | 1,5 |
Rated Speed, m/s | 12 |
Cut-in Speed, m/s | 4 |
Survival Speed, m/s | 45 |
Blades Material | glass fibre |
Wind Generator Type | Permanent magnet, magnetic levitation and coreless disc type generator |
Working environment humidness | ≤90% |
Altitude | ≤4500 |
Install Height, m | 6~12 |
Overload Protection | Electromagnetic Brake |
Producer | R&X Energy |
Protection | IP54 |
Noise level ,dB | 30 |
Packaging | 17x17x132cm; 55x35x35cm |
Operating temperature | -40°C +40°C |
Series | Spiral Type |
Country of Origin | China |
Gross weight, kg | 28 |
Download instructions, catalog for Spiral wind turbine RX-SV1000 1 kW vertical
