Contact material | AISI |
Producer | BTS Engineering |
Pump capacity, cu.m/hour | 7.18 |
Feed height, m | 160 |
Power capacity, kW | 4 |
Material | cast iron |
Input pipe diameter | 2" |
Output pipe diameter | 2" |
Rate of turn, rpm | 41 |
Power supply | 3х380 V, 50 Hz |
Max.flow rate, m3/h | 17.5 |
Max.temperature, C | 80 |
Max. head, m | 160 |
Max.diameter of solid inclusions, mm | 8,3 |
Flow rate, l/h | 7175 |
Nom.flow rate, m3/h | 7.18 |
Dimensions, mm | 870,5x838x781,5 |
Pressure, bar | 16 |
Material for working hoos | NBR |
Housing material | Сast iron |
Max.dry suction head, m | 9,5 |
Serial number of the pump | JXHIN |
Country of Origin | China |
PumpType | peristaltic |
Drive Type | electric |
Weight, kg | 282 |
Contact material | AISI |
Producer | BTS Engineering |
Pump capacity, cu.m/hour | 7.18 |
Feed height, m | 160 |
Power capacity, kW | 4 |
Material | cast iron |
Input pipe diameter | 2" |
Output pipe diameter | 2" |
Rate of turn, rpm | 41 |
Power supply | 3х380 V, 50 Hz |
Max.flow rate, m3/h | 17.5 |
Max.temperature, C | 80 |
Max. head, m | 160 |
Max.diameter of solid inclusions, mm | 8,3 |
Flow rate, l/h | 7175 |
Nom.flow rate, m3/h | 7.18 |
Dimensions, mm | 870,5x838x781,5 |
Pressure, bar | 16 |
Material for working hoos | NBR |
Housing material | Сast iron |
Max.dry suction head, m | 9,5 |
Serial number of the pump | JXHIN |
Country of Origin | China |
PumpType | peristaltic |
Drive Type | electric |
Weight, kg | 282 |
Download instructions, catalog for Industrial hose pump JXHIN-50-CI+SS-NBR-P, 7.18 m3/h, 4 kW, 16 bar, 380V
