Producer | BTS Engineering |
Pump capacity, cu.m/hour | 6 |
Feed height, m | 30 |
Material | AISI 304 stainless steel |
Input pipe diameter | 42 |
Output pipe diameter | 25 |
Rate of turn, rpm | 12 000 |
Power supply | 1х220 V, 50 Hz |
Explosion protection | Yes |
Max.temperature, C | 100 |
Material of flow channel | AISI 304 stainless steel |
Max. head, m | 30 |
Max.viscosity, cPs | 80 |
Flow rate, l/min | 100 |
Model | BTS НР |
Power capacity, Wt | 880 |
Height, mm | 1 000 |
Length, mm | 1000 |
Shaft material | AISI 316L |
Country of Origin | China |
PumpType | drum |
Drive Type | electric |
Type of configuration | with engine |
Availability of spare parts | yes |
Warranty, months | 12 |
Application | CIP-washing, barrels, eurocube, hardeners, enzymes, nitric acid, acid, acetic acid, chemistry, alkalis, pigments, oils, solvents, fuel, chemically active liquids, hydrofluoric acid, of hydrochloric acid, food additives, food, molasses, thickeners, flavorings, petroleum products |
Analogue for | FLUIMAC, DAYTON, Debem, JESSBERGER, Lutz |
Producer | BTS Engineering |
Pump capacity, cu.m/hour | 6 |
Feed height, m | 30 |
Material | AISI 304 stainless steel |
Input pipe diameter | 42 |
Output pipe diameter | 25 |
Rate of turn, rpm | 12 000 |
Power supply | 1х220 V, 50 Hz |
Explosion protection | Yes |
Max.temperature, C | 100 |
Material of flow channel | AISI 304 stainless steel |
Max. head, m | 30 |
Max.viscosity, cPs | 80 |
Flow rate, l/min | 100 |
Model | BTS НР |
Power capacity, Wt | 880 |
Height, mm | 1 000 |
Length, mm | 1000 |
Shaft material | AISI 316L |
Country of Origin | China |
PumpType | drum |
Drive Type | electric |
Type of configuration | with engine |
Availability of spare parts | yes |
Warranty, months | 12 |
Application | CIP-washing, barrels, eurocube, hardeners, enzymes, nitric acid, acid, acetic acid, chemistry, alkalis, pigments, oils, solvents, fuel, chemically active liquids, hydrofluoric acid, of hydrochloric acid, food additives, food, molasses, thickeners, flavorings, petroleum products |
Analogue for | FLUIMAC, DAYTON, Debem, JESSBERGER, Lutz |
Download instructions, catalog for Drum pump BTS-HD-EX2-V+SS304-HP-1000mm
