Producer | BTS Engineering |
Pump capacity, cu.m/hour | 6 |
Feed height, m | 10 |
Material | AISI 316L |
Input pipe diameter | 42 |
Output pipe diameter | 25 |
Rate of turn, rpm | 10 000 |
Power supply | 1х220 V, 50 Hz |
Explosion protection | No |
Max.temperature, C | 100 |
Material of flow channel | AISI 316L |
Max. head, m | 10 |
Max.viscosity, cPs | 800 |
Flow rate, l/min | 100 |
Model | BTS |
Power capacity, Wt | 800 |
Height, mm | 1 000 |
Length, mm | 1000 |
Shaft material | AISI 316L |
Country of Origin | China |
PumpType | drum |
Drive Type | electric |
Type of configuration | with engine |
Availability of spare parts | yes |
Warranty, months | 12 |
Application | eurocube, CIP-washing, barrels, oils, nitric acid, acid, acetic acid, chemistry, alkalis, pigments, enzymes, fuel, hardeners, chemically active liquids, hydrofluoric acid, of hydrochloric acid, food additives, food, molasses, thickeners, flavorings, petroleum products, solvents |
Analogue for | FLUIMAC, DAYTON, Debem, JESSBERGER, Lutz |
