Diameter of pump | 8" (200 mm) |
Producer | EDWIN |
Pump capacity, cu.m/hour | 90 |
Feed height, m | 139 |
Power capacity, kW | 26 |
Material | AISI 304 stainless steel |
Output pipe diameter | 5" |
Rate of turn, rpm | 2 850 |
Power supply | 3х380 V, 50 Hz |
Max.flow rate, m3/h | 90 |
Max. head, m | 139 |
Housing material | AISI 304 stainless steel |
Serial number of the pump | 8SP |
Country of Origin | China |
PumpType | borehole |
Drive Type | electric |
Diameter of pump | 8" (200 mm) |
Producer | EDWIN |
Pump capacity, cu.m/hour | 90 |
Feed height, m | 139 |
Power capacity, kW | 26 |
Material | AISI 304 stainless steel |
Output pipe diameter | 5" |
Rate of turn, rpm | 2 850 |
Power supply | 3х380 V, 50 Hz |
Max.flow rate, m3/h | 90 |
Max. head, m | 139 |
Housing material | AISI 304 stainless steel |
Serial number of the pump | 8SP |
Country of Origin | China |
PumpType | borehole |
Drive Type | electric |
Download instructions, catalog for Submersible well pump 8SP77/07, Outlet: 5 inches, 26 kW, 380V
