Producer | BTS Engineering |
Pump capacity, cu.m/hour | 48 |
Feed height, m | 57 |
Power capacity, kW | 7,5 |
Material | cast iron |
Input pipe diameter | DN50 |
Output pipe diameter | DN50 |
Rate of turn, rpm | 2 900 |
Protection | IP55 |
Power supply | 3х380 V, 50 Hz |
Max.flow rate, m3/h | 48 |
Max.temperature, C | 120 |
Max. head, m | 57 |
Seal | Mechanical Seal, Carbon-SiC-NBR |
Impeller material | AISI 304 stainless steel |
Serial number of the pump | BT |
Country of Origin | China |
PumpType | in-line |
Drive Type | electric |
Installation Type | vertical |
Type of configuration | with engine |
Warranty, months | 12 |
Application | circulation, boiler, hot water, coolant, ethylene glycol, water recycling, increasing pressure, air conditioning systems, heating, DHW, drying, glycol, water, cooling, cooling tower, hot water, ice water, the drying chamber, water, water supply, glaze |
Analogue for | KOLMEKS |
Weight, kg | 73 |
Height of transport volume, cbm | 0,077 |
Producer | BTS Engineering |
Pump capacity, cu.m/hour | 48 |
Feed height, m | 57 |
Power capacity, kW | 7,5 |
Material | cast iron |
Input pipe diameter | DN50 |
Output pipe diameter | DN50 |
Rate of turn, rpm | 2 900 |
Protection | IP55 |
Power supply | 3х380 V, 50 Hz |
Max.flow rate, m3/h | 48 |
Max.temperature, C | 120 |
Max. head, m | 57 |
Seal | Mechanical Seal, Carbon-SiC-NBR |
Impeller material | AISI 304 stainless steel |
Serial number of the pump | BT |
Country of Origin | China |
PumpType | in-line |
Drive Type | electric |
Installation Type | vertical |
Type of configuration | with engine |
Warranty, months | 12 |
Application | circulation, boiler, hot water, coolant, ethylene glycol, water recycling, increasing pressure, air conditioning systems, heating, DHW, drying, glycol, water, cooling, cooling tower, hot water, ice water, the drying chamber, water, water supply, glaze |
Analogue for | KOLMEKS |
Weight, kg | 73 |
Height of transport volume, cbm | 0,077 |
Download instructions, catalog for BT 50-570/7,5 pump in-line
