Producer | BTS Engineering |
Pump capacity, cu.m/hour | 72 |
Feed height, m | 18 |
Power capacity, kW | 5,5 |
Material | AISI 304 stainless steel |
Input pipe diameter | DN80 |
Output pipe diameter | DN65 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | No |
Max.flow rate, m3/h | 120 |
Nom.pressure, Mpa | 1 |
Max.temperature, C | 120 |
Material of flow channel | AISI 304 stainless steel |
Max. head, m | 26 |
Nom.flow rate, m3/h | 72 |
Nom.head, m | 18 |
Serial number of the pump | SM |
Country of Origin | China |
PumpType | console |
Drive Type | electric |
Installation Type | horizontal |
Availability of spare parts | yes |
Warranty, months | 12 |
Application | salt, CIP-washing, food, water recycling, increasing pressure, water, glaze, the drying chamber, ice water, cooling tower, drying, caustic, juices, milk, wort, ammonia mixture, CAS, wine, liquid fertilizer, cheesecloth, urea, brew, mudflow solution, brogue, heating |
Analogue for | Pentax, Onga, Omnigena, Odwerk, Nocchi, LOWARA, Kripsol, Simaco, SAER, PERKINS, PentairSwimmey, Hydro-Vacuum, Packo, TEREX, TAJFUN, Svanehoj, Sprut, Speroni, SOMA, Greenpumps, OMAC, Zenit, Honda, HYPRO, ThuneEureka, DPPumps, AlfaLaval, Calpeda, Bronzoni, ASTA, Aquatechnika, Aquario, APV, Ebara, Alweller, Varna, Johnson, DAB, Cornell, Hobart, Hilge, Hidrostal, FRISTAM, Foras, Flygt, KOLMEKS, Kenle, Unitech, KSB, Sterling, INOXPA, Allweiler, Grundfos, SIHI, Wilo, GEA, Rovatti, CAPRARI, Varisco |
Producer | BTS Engineering |
Pump capacity, cu.m/hour | 72 |
Feed height, m | 18 |
Power capacity, kW | 5,5 |
Material | AISI 304 stainless steel |
Input pipe diameter | DN80 |
Output pipe diameter | DN65 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | No |
Max.flow rate, m3/h | 120 |
Nom.pressure, Mpa | 1 |
Max.temperature, C | 120 |
Material of flow channel | AISI 304 stainless steel |
Max. head, m | 26 |
Nom.flow rate, m3/h | 72 |
Nom.head, m | 18 |
Serial number of the pump | SM |
Country of Origin | China |
PumpType | console |
Drive Type | electric |
Installation Type | horizontal |
Availability of spare parts | yes |
Warranty, months | 12 |
Application | salt, CIP-washing, food, water recycling, increasing pressure, water, glaze, the drying chamber, ice water, cooling tower, drying, caustic, juices, milk, wort, ammonia mixture, CAS, wine, liquid fertilizer, cheesecloth, urea, brew, mudflow solution, brogue, heating |
Analogue for | Pentax, Onga, Omnigena, Odwerk, Nocchi, LOWARA, Kripsol, Simaco, SAER, PERKINS, PentairSwimmey, Hydro-Vacuum, Packo, TEREX, TAJFUN, Svanehoj, Sprut, Speroni, SOMA, Greenpumps, OMAC, Zenit, Honda, HYPRO, ThuneEureka, DPPumps, AlfaLaval, Calpeda, Bronzoni, ASTA, Aquatechnika, Aquario, APV, Ebara, Alweller, Varna, Johnson, DAB, Cornell, Hobart, Hilge, Hidrostal, FRISTAM, Foras, Flygt, KOLMEKS, Kenle, Unitech, KSB, Sterling, INOXPA, Allweiler, Grundfos, SIHI, Wilo, GEA, Rovatti, CAPRARI, Varisco |
Download instructions, catalog for Pump GZA 80-65-125/5,5
