| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 7.2 |
| Feed height, m | 14 |
| Power capacity, kW | 0,37 |
| Material | cast iron |
| Input pipe diameter | DN32 |
| Output pipe diameter | DN32 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 7.2 |
| Nom.pressure, Mpa | 1,6 |
| Max.temperature, C | 120 |
| Material of flow channel | cast iron |
| Max. head, m | 14 |
| Volume, m3 | 0,031 |
| Net weight,kg | 16 |
| Serial number of the pump | JL |
| Country of Origin | China |
| PumpType | in-line |
| Drive Type | electric |
| Installation Type | vertical |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | air conditioning systems, water, the drying chamber, ice water, hot water, cooling tower, cooling, glycol, glaze, drying, DHW, heating, water supply, water, increasing pressure, coolant, hot water, boiler, circulation, ethylene glycol, water recycling |
| Analogue for | CALPEDA NM, CALPEDA NR, CALPEDA NC, KSB Etaline-R, KSB Etanorm, KSB Calio S, DAB ALP, DAB CM-G, DAB CM, DAB DKLP, AB DKLM, DAB KLP, DAB KLM, DAB ALM, KSB Calio, DAB DCM, DAB DCM-G, DAB CP, WILO TOP-S, KSB Etaline, PSPRUT 3VP, SPRUT 1V, SPRUT 3VP, SPRUT GPD, Speroni SCR, WILO CronoLine-IL-E, DAB CP-G, WILO VeroLine-IPL, EBARA LPS, EBARA EGO EASY, Grundfos UPS, DAB DCP-G, DAB DCP |
| Weight, kg | 17 |
| Producer | BTS Engineering |
| Pump capacity, cu.m/hour | 7.2 |
| Feed height, m | 14 |
| Power capacity, kW | 0,37 |
| Material | cast iron |
| Input pipe diameter | DN32 |
| Output pipe diameter | DN32 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 7.2 |
| Nom.pressure, Mpa | 1,6 |
| Max.temperature, C | 120 |
| Material of flow channel | cast iron |
| Max. head, m | 14 |
| Volume, m3 | 0,031 |
| Net weight,kg | 16 |
| Serial number of the pump | JL |
| Country of Origin | China |
| PumpType | in-line |
| Drive Type | electric |
| Installation Type | vertical |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | air conditioning systems, water, the drying chamber, ice water, hot water, cooling tower, cooling, glycol, glaze, drying, DHW, heating, water supply, water, increasing pressure, coolant, hot water, boiler, circulation, ethylene glycol, water recycling |
| Analogue for | CALPEDA NM, CALPEDA NR, CALPEDA NC, KSB Etaline-R, KSB Etanorm, KSB Calio S, DAB ALP, DAB CM-G, DAB CM, DAB DKLP, AB DKLM, DAB KLP, DAB KLM, DAB ALM, KSB Calio, DAB DCM, DAB DCM-G, DAB CP, WILO TOP-S, KSB Etaline, PSPRUT 3VP, SPRUT 1V, SPRUT 3VP, SPRUT GPD, Speroni SCR, WILO CronoLine-IL-E, DAB CP-G, WILO VeroLine-IPL, EBARA LPS, EBARA EGO EASY, Grundfos UPS, DAB DCP-G, DAB DCP |
| Weight, kg | 17 |
Download instructions, catalog for JL 32T Centrifugal pump
