| Producer | DiaPump |
| Pump capacity, cu.m/hour | 3.42 |
| Feed height, m | 80 |
| Material | PVDF |
| Noise level ,dB | 65 |
| Explosion protection | Yes |
| ATEX standard | Ex II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C) |
| Max.flow rate, m3/h | 3.42 |
| Max.temperature, C | 95 |
| Material of flow channel | PVDF |
| Max. head, m | 80 |
| Diaphragm material at water side | PTFE |
| Max.viscosity, cPs | 20 000 |
| Max.air pressure, bar | 8,4 |
| Flow rate, l/min | 57 |
| Max.diameter of solid inclusions, mm | 3 |
| Model | DP 05 |
| Diametr of the product line | 3/4" |
| Diameter of the pneumatic mainline | 1/4" |
| Dry suction height, m | 6 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | DP |
| Country of Origin | Turkey |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | urea, reverse osmosis systems, sulfur, peroxide, oleum, saturated amine, varnish, paints, carbonate, kaolin suspension, acetic acid, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid, alcohol, phenol, formalin, ethers, ethylene, alkalis, slip, slag, phosphoric acid, phosphates |
| Analogue for | YAMADA NDP, WILDEN, Sera, Seko, AGRAL DDE-100, Astralpool, AquaViva, AQUA, AlphaDynamic Ruby, AGRAL DDE-600, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-030, ProMinent, Debem BOXER, Debem FOODBOXER, Debem SANIBOXER, DELLMECO DM, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC, DEPA РМ (Р), DEPA М, DEPA L, DEPA DB, DELLMECO DMCX |
| Weight, kg | 4,5 |
| Producer | DiaPump |
| Pump capacity, cu.m/hour | 3.42 |
| Feed height, m | 80 |
| Material | PVDF |
| Noise level ,dB | 65 |
| Explosion protection | Yes |
| ATEX standard | Ex II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C) |
| Max.flow rate, m3/h | 3.42 |
| Max.temperature, C | 95 |
| Material of flow channel | PVDF |
| Max. head, m | 80 |
| Diaphragm material at water side | PTFE |
| Max.viscosity, cPs | 20 000 |
| Max.air pressure, bar | 8,4 |
| Flow rate, l/min | 57 |
| Max.diameter of solid inclusions, mm | 3 |
| Model | DP 05 |
| Diametr of the product line | 3/4" |
| Diameter of the pneumatic mainline | 1/4" |
| Dry suction height, m | 6 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | DP |
| Country of Origin | Turkey |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | urea, reverse osmosis systems, sulfur, peroxide, oleum, saturated amine, varnish, paints, carbonate, kaolin suspension, acetic acid, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid, alcohol, phenol, formalin, ethers, ethylene, alkalis, slip, slag, phosphoric acid, phosphates |
| Analogue for | YAMADA NDP, WILDEN, Sera, Seko, AGRAL DDE-100, Astralpool, AquaViva, AQUA, AlphaDynamic Ruby, AGRAL DDE-600, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-030, ProMinent, Debem BOXER, Debem FOODBOXER, Debem SANIBOXER, DELLMECO DM, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC, DEPA РМ (Р), DEPA М, DEPA L, DEPA DB, DELLMECO DMCX |
| Weight, kg | 4,5 |
Download instructions, catalog for DP 05 PVDF/T - Pneumatic Membrane Pump
