| Producer | DiaPump |
| Pump capacity, cu.m/hour | 24 |
| Feed height, m | 80 |
| Material | PP |
| Noise level ,dB | 65 |
| Explosion protection | Yes |
| ATEX standard | Ex II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C) |
| Max.flow rate, m3/h | 24 |
| Max.temperature, C | 65 |
| Material of flow channel | PP |
| Max. head, m | 80 |
| Diaphragm material at water side | EPDM |
| Max.viscosity, cPs | 45 000 |
| Max.air pressure, bar | 8,4 |
| Flow rate, l/min | 400 |
| Max.diameter of solid inclusions, mm | 6 |
| Model | DP 15 |
| Diametr of the product line | 1 1/2" |
| Diameter of the pneumatic mainline | 3/4" |
| Dry suction height, m | 6 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | DP |
| Country of Origin | Turkey |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | paints, acetic acid, alcohol, reverse osmosis systems, sulfur, peroxide, oleum, saturated amine, varnish, carbonate, formalin, urea, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, phenol, phosphates, phosphoric acid, ethers, ethylene, alkalis, slip, slag, nitric acid |
| Analogue for | AlphaDynamic Ruby, DELLMECO DMCX, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool, AquaViva, AQUA, AGRAL DDE-600, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, DEPA DB, DEPA L, DEPA М, DEPA РМ (Р), YAMADA NDP, WILDEN, Sera, Seko, ProMinent, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC |
| Weight, kg | 20,5 |
| Producer | DiaPump |
| Pump capacity, cu.m/hour | 24 |
| Feed height, m | 80 |
| Material | PP |
| Noise level ,dB | 65 |
| Explosion protection | Yes |
| ATEX standard | Ex II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C) |
| Max.flow rate, m3/h | 24 |
| Max.temperature, C | 65 |
| Material of flow channel | PP |
| Max. head, m | 80 |
| Diaphragm material at water side | EPDM |
| Max.viscosity, cPs | 45 000 |
| Max.air pressure, bar | 8,4 |
| Flow rate, l/min | 400 |
| Max.diameter of solid inclusions, mm | 6 |
| Model | DP 15 |
| Diametr of the product line | 1 1/2" |
| Diameter of the pneumatic mainline | 3/4" |
| Dry suction height, m | 6 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | DP |
| Country of Origin | Turkey |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | paints, acetic acid, alcohol, reverse osmosis systems, sulfur, peroxide, oleum, saturated amine, varnish, carbonate, formalin, urea, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, phenol, phosphates, phosphoric acid, ethers, ethylene, alkalis, slip, slag, nitric acid |
| Analogue for | AlphaDynamic Ruby, DELLMECO DMCX, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool, AquaViva, AQUA, AGRAL DDE-600, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, DEPA DB, DEPA L, DEPA М, DEPA РМ (Р), YAMADA NDP, WILDEN, Sera, Seko, ProMinent, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC |
| Weight, kg | 20,5 |
Download instructions, catalog for DP 15 PP/E - PB/E - Pneumatic Membrane Pump
