| Producer | DiaPump |
| Pump capacity, cu.m/hour | 24 |
| Feed height, m | 80 |
| Material | AISI 316L |
| Noise level ,dB | 65 |
| Explosion protection | Yes |
| ATEX standard | Ex II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C) |
| Max.flow rate, m3/h | 24 |
| Max.temperature, C | 95 |
| Material of flow channel | AISI 316L |
| Max. head, m | 80 |
| Diaphragm material at water side | FKM |
| Max.viscosity, cPs | 45 000 |
| Max.air pressure, bar | 8,4 |
| Flow rate, l/min | 400 |
| Max.diameter of solid inclusions, mm | 6 |
| Model | DP 15 |
| Diametr of the product line | 1 1/2" |
| Diameter of the pneumatic mainline | 3/4" |
| Dry suction height, m | 6 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | DP |
| Country of Origin | Turkey |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | saturated amine, formalin, phenol, acetic acid, alcohol, reverse osmosis systems, sulfur, peroxide, oleum, varnish, phosphoric acid, paints, carbonate, urea, kaolin suspension, ash, clays, viscous liquids, hydrogen, phosphates, slag, slip, ethers, ethylene, alkalis, butane, ammonia, nitric acid |
| Analogue for | AGRAL DDE-600, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool, AquaViva, AQUA, AlphaDynamic Ruby, AGRAL DDE-60, YAMADA NDP, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, DELLMECO DMCX, DEPA DB, DEPA L, DEPA М, WILDEN, Sera, Seko, ProMinent, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC, DEPA РМ (Р) |
| Weight, kg | 26 |
| Producer | DiaPump |
| Pump capacity, cu.m/hour | 24 |
| Feed height, m | 80 |
| Material | AISI 316L |
| Noise level ,dB | 65 |
| Explosion protection | Yes |
| ATEX standard | Ex II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C) |
| Max.flow rate, m3/h | 24 |
| Max.temperature, C | 95 |
| Material of flow channel | AISI 316L |
| Max. head, m | 80 |
| Diaphragm material at water side | FKM |
| Max.viscosity, cPs | 45 000 |
| Max.air pressure, bar | 8,4 |
| Flow rate, l/min | 400 |
| Max.diameter of solid inclusions, mm | 6 |
| Model | DP 15 |
| Diametr of the product line | 1 1/2" |
| Diameter of the pneumatic mainline | 3/4" |
| Dry suction height, m | 6 |
| Suction capacity (NPSH), m | 9,8 |
| Serial number of the pump | DP |
| Country of Origin | Turkey |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Warranty, months | 12 |
| Application | saturated amine, formalin, phenol, acetic acid, alcohol, reverse osmosis systems, sulfur, peroxide, oleum, varnish, phosphoric acid, paints, carbonate, urea, kaolin suspension, ash, clays, viscous liquids, hydrogen, phosphates, slag, slip, ethers, ethylene, alkalis, butane, ammonia, nitric acid |
| Analogue for | AGRAL DDE-600, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool, AquaViva, AQUA, AlphaDynamic Ruby, AGRAL DDE-60, YAMADA NDP, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, DELLMECO DMCX, DEPA DB, DEPA L, DEPA М, WILDEN, Sera, Seko, ProMinent, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC, DEPA РМ (Р) |
| Weight, kg | 26 |
Download instructions, catalog for DP 15 SC/V - Pneumatic Membrane Pump
