| Producer | DEBEM |
| Pump capacity, cu.m/hour | 20.4 |
| Feed height, m | 70 |
| Material | AISI 316 stainless steel |
| Input pipe diameter | 1" 1/2 |
| Output pipe diameter | 1" 1/2 |
| Max.flow rate, m3/h | 20.4 |
| Max.temperature, C | 95 |
| Material of flow channel | AISI 316 stainless steel |
| Max. head, m | 70 |
| Diaphragm material at air side | HYTREL |
| Diaphragm material at water side | PTFE |
| Material of ball valves | AISI 316 stainless steel |
| Material of valve seat | AISI 316 stainless steel |
| Max.viscosity, cPs | 50 000 |
| Max.air pressure, bar | 7 |
| Flow rate, l/min | 340 |
| Max.diameter of solid inclusions, mm | 6 |
| Model | BOXER 252 |
| Material of O-ring | PTFE |
| Max.dry suction head, m | 6 |
| Pneumatic circuit connection, inch, f | 1/2" |
| Serial number of the pump | BOXER |
| Country of Origin | Italy |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Application | carbonate, alcohol, reverse osmosis systems, sulfur, peroxide, oleum, saturated amine, varnish, paints, urea, phenol, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid, acetic acid, formalin, phosphates, ethers, ethylene, alkalis, slip, slag, phosphoric acid |
| Analogue for | AlphaDynamic Ruby, DELLMECO DMCX, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool, AquaViva, AQUA, AGRAL DDE-600, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, DEPA DB, DEPA L, DEPA М, DEPA РМ (Р), YAMADA NDP, WILDEN, Sera, Seko, ProMinent, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC |
| Weight, kg | 32 |
| Producer | DEBEM |
| Pump capacity, cu.m/hour | 20.4 |
| Feed height, m | 70 |
| Material | AISI 316 stainless steel |
| Input pipe diameter | 1" 1/2 |
| Output pipe diameter | 1" 1/2 |
| Max.flow rate, m3/h | 20.4 |
| Max.temperature, C | 95 |
| Material of flow channel | AISI 316 stainless steel |
| Max. head, m | 70 |
| Diaphragm material at air side | HYTREL |
| Diaphragm material at water side | PTFE |
| Material of ball valves | AISI 316 stainless steel |
| Material of valve seat | AISI 316 stainless steel |
| Max.viscosity, cPs | 50 000 |
| Max.air pressure, bar | 7 |
| Flow rate, l/min | 340 |
| Max.diameter of solid inclusions, mm | 6 |
| Model | BOXER 252 |
| Material of O-ring | PTFE |
| Max.dry suction head, m | 6 |
| Pneumatic circuit connection, inch, f | 1/2" |
| Serial number of the pump | BOXER |
| Country of Origin | Italy |
| PumpType | membrane pneumatic |
| Drive Type | pneumatic |
| Availability of spare parts | yes |
| Application | carbonate, alcohol, reverse osmosis systems, sulfur, peroxide, oleum, saturated amine, varnish, paints, urea, phenol, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid, acetic acid, formalin, phosphates, ethers, ethylene, alkalis, slip, slag, phosphoric acid |
| Analogue for | AlphaDynamic Ruby, DELLMECO DMCX, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool, AquaViva, AQUA, AGRAL DDE-600, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, DEPA DB, DEPA L, DEPA М, DEPA РМ (Р), YAMADA NDP, WILDEN, Sera, Seko, ProMinent, PRODOSE, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC |
| Weight, kg | 32 |
Download instructions, catalog for The pneumatic diaphragm pumps BOXER 252 AISI 316 IB252A-HTAAT--
