Temperature (min), °C | -20 |
Producer | FLUIMAC |
Pump capacity, m3/h | 7.2 |
Feed height, m | 80 |
Material | PVDF |
Input pipe diameter | 1" |
Output pipe diameter | 1" |
Noise level ,dB | 72 |
Explosion protection | Yes |
ATEX standard | II 3/3 G Ex h IIC T4 Gc; II 3 D Ex h IIIB T135°C Dc X |
Max.flow rate, m3/h | 7.2 |
Max.temperature, C | 95 |
Material of flow channel | PVDF |
Max. head, m | 80 |
Diaphragm material at air side | SANTOPRENE |
Diaphragm material at water side | PTFE |
Material of ball valves | PTFE |
Material of valve seat | PVDF |
Max.viscosity, cPs | 25 000 |
Max.air pressure, bar | 8 |
Flow rate, l/min | 120 |
Max.diameter of solid inclusions, mm | 4 |
Model | PHOENIX 120 |
Diametr of the product line | 1" |
Diameter of the pneumatic mainline | 3/8" |
Dry suction height, m | 5 |
Suction capacity (NPSH), m | 9,8 |
Dimensions, mm | 293x179x280 |
Serial number of the pump | PHOENIX |
Country of Origin | Italy |
PumpType | membrane pneumatic |
Drive Type | pneumatic |
Availability of spare parts | Yes |
Warranty, months | 12 |
Application | viscous liquids, oleum, saturated amine, varnish, paints, carbonate, urea, kaolin suspension, ash, clays, hydrogen, sulfur, butane, ammonia, nitric acid, peroxide, reverse osmosis systems, ethers, alcohol, ethylene, alkalis, slip, slag, phosphoric acid, phosphates, formalin, phenol, acetic acid |
Analogue for | YAMADA NDP, WILDEN, Sera, Seko, PRODOSE, ProMinent, Milwaukee, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, AlphaDynamic Ruby, AGRAL DDE-600, AQUA, MILTON ROY, AquaViva, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC, DEPA РМ (Р), DEPA М, DEPA L, DEPA DB, DELLMECO DMCX, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool |
Weight, kg | 7,6 |
Temperature (min), °C | -20 |
Producer | FLUIMAC |
Pump capacity, m3/h | 7.2 |
Feed height, m | 80 |
Material | PVDF |
Input pipe diameter | 1" |
Output pipe diameter | 1" |
Noise level ,dB | 72 |
Explosion protection | Yes |
ATEX standard | II 3/3 G Ex h IIC T4 Gc; II 3 D Ex h IIIB T135°C Dc X |
Max.flow rate, m3/h | 7.2 |
Max.temperature, C | 95 |
Material of flow channel | PVDF |
Max. head, m | 80 |
Diaphragm material at air side | SANTOPRENE |
Diaphragm material at water side | PTFE |
Material of ball valves | PTFE |
Material of valve seat | PVDF |
Max.viscosity, cPs | 25 000 |
Max.air pressure, bar | 8 |
Flow rate, l/min | 120 |
Max.diameter of solid inclusions, mm | 4 |
Model | PHOENIX 120 |
Diametr of the product line | 1" |
Diameter of the pneumatic mainline | 3/8" |
Dry suction height, m | 5 |
Suction capacity (NPSH), m | 9,8 |
Dimensions, mm | 293x179x280 |
Serial number of the pump | PHOENIX |
Country of Origin | Italy |
PumpType | membrane pneumatic |
Drive Type | pneumatic |
Availability of spare parts | Yes |
Warranty, months | 12 |
Application | viscous liquids, oleum, saturated amine, varnish, paints, carbonate, urea, kaolin suspension, ash, clays, hydrogen, sulfur, butane, ammonia, nitric acid, peroxide, reverse osmosis systems, ethers, alcohol, ethylene, alkalis, slip, slag, phosphoric acid, phosphates, formalin, phenol, acetic acid |
Analogue for | YAMADA NDP, WILDEN, Sera, Seko, PRODOSE, ProMinent, Milwaukee, AGRAL DDE-60, AGRAL DDE-300, AGRAL DDE-160, AGRAL DDE-100, AGRAL DDE-030, AlphaDynamic Ruby, AGRAL DDE-600, AQUA, MILTON ROY, AquaViva, Jesco Pump, Injecta, Grundfos, Graco Husky, FWT, Emec, DUOTEK SANI, DUOTEK FOOD, Duotek AF Zone 2 Atex, DOSITEC, DEPA РМ (Р), DEPA М, DEPA L, DEPA DB, DELLMECO DMCX, DELLMECO DM, Debem SANIBOXER, Debem FOODBOXER, Debem BOXER, Astralpool |
Weight, kg | 7,6 |
