Producer | BTS Engineering |
Pump capacity, cu.m/hour | 3.5 |
Feed height, m | 18 |
Power capacity, kW | 0,37 |
Material | AISI 304 stainless steel |
Input pipe diameter | DN25 |
Output pipe diameter | DN25 |
Rate of turn, rpm | 2 900 |
Protection | IP55 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | No |
Max.flow rate, m3/h | 3.5 |
Max.temperature, C | 120 |
Material of flow channel | AISI 304 stainless steel |
Max. head, m | 18 |
Seal | Mechanical Seal |
Impeller material | AISI 304 stainless steel |
Nom.flow rate, m3/h | 2 |
Nom.head, m | 15 |
Housing material | AISI 304 stainless steel |
Serial number of the pump | BVS |
Country of Origin | China |
PumpType | multi-stage |
Drive Type | electric |
Installation Type | vertical |
Type of configuration | with engine |
Warranty, months | 12 |
Application | osmosis, Water Treatment, fountain, steam boiler, water treatment, membranes, washing, jets, wash, aeroponics, greenhouses, hydroponics, hot water, water, water, increasing pressure, boiler, alkalis, caustic, irrigation |
Analogue for | Calpeda MXV, Dab KVC, Aquatica LVR, Lowara SV, VMtec PRIMA VMEV, Speroni RVM, Grundfos CR, Ebara EVMS, EBARA EVMW, Varna, EBARA EVM |
Weight, kg | 20 |
Length of transport packing, cm | 27 |
Width of transport packing, cm | 27 |
Height of transport packing, cm | 50 |
Height of transport volume, cbm | 0,036 |
Producer | BTS Engineering |
Pump capacity, cu.m/hour | 3.5 |
Feed height, m | 18 |
Power capacity, kW | 0,37 |
Material | AISI 304 stainless steel |
Input pipe diameter | DN25 |
Output pipe diameter | DN25 |
Rate of turn, rpm | 2 900 |
Protection | IP55 |
Power supply | 3х380 V, 50 Hz |
Explosion protection | No |
Max.flow rate, m3/h | 3.5 |
Max.temperature, C | 120 |
Material of flow channel | AISI 304 stainless steel |
Max. head, m | 18 |
Seal | Mechanical Seal |
Impeller material | AISI 304 stainless steel |
Nom.flow rate, m3/h | 2 |
Nom.head, m | 15 |
Housing material | AISI 304 stainless steel |
Serial number of the pump | BVS |
Country of Origin | China |
PumpType | multi-stage |
Drive Type | electric |
Installation Type | vertical |
Type of configuration | with engine |
Warranty, months | 12 |
Application | osmosis, Water Treatment, fountain, steam boiler, water treatment, membranes, washing, jets, wash, aeroponics, greenhouses, hydroponics, hot water, water, water, increasing pressure, boiler, alkalis, caustic, irrigation |
Analogue for | Calpeda MXV, Dab KVC, Aquatica LVR, Lowara SV, VMtec PRIMA VMEV, Speroni RVM, Grundfos CR, Ebara EVMS, EBARA EVMW, Varna, EBARA EVM |
Weight, kg | 20 |
Length of transport packing, cm | 27 |
Width of transport packing, cm | 27 |
Height of transport packing, cm | 50 |
Height of transport volume, cbm | 0,036 |
Download instructions, catalog for Multistage vertical pump BVS 2-2, 0.37 kW, AISI 304
