Maximal altitude of immersion under the water surface, m | 20 |
Motor capacitor capacity, µF | 20 |
Impeller type | vortex impeller |
Producer | Dreno |
Pump capacity, cu.m/hour | 21.6 |
Feed height, m | 11.5 |
Power capacity, kW | 0,75 |
Output pipe diameter | G1 1/2 |
Rate of turn, rpm | 2 850 |
Protection | IP68 |
Power supply | 1х220 V, 50 Hz |
Explosion protection | No |
Max.flow rate, m3/h | 21.6 |
Max.temperature, C | 40 |
Max. head, m | 11.5 |
Max.diameter of solid inclusions, mm | 35 |
Seal | Double Mechanical Seal, CA/CE/Viton - SIC/SIC/Viton |
Shaft material | AISI 420 |
Impeller material | cast iron |
Housing material | Сast iron |
Serial number of the pump | ALPHA V EVO |
Country of Origin | Italy |
PumpType | submersible drainage and fecal |
Drive Type | electric |
Installation Type | vertical |
Weight, kg | 17,5 |
Maximal altitude of immersion under the water surface, m | 20 |
Motor capacitor capacity, µF | 20 |
Impeller type | vortex impeller |
Producer | Dreno |
Pump capacity, cu.m/hour | 21.6 |
Feed height, m | 11.5 |
Power capacity, kW | 0,75 |
Output pipe diameter | G1 1/2 |
Rate of turn, rpm | 2 850 |
Protection | IP68 |
Power supply | 1х220 V, 50 Hz |
Explosion protection | No |
Max.flow rate, m3/h | 21.6 |
Max.temperature, C | 40 |
Max. head, m | 11.5 |
Max.diameter of solid inclusions, mm | 35 |
Seal | Double Mechanical Seal, CA/CE/Viton - SIC/SIC/Viton |
Shaft material | AISI 420 |
Impeller material | cast iron |
Housing material | Сast iron |
Serial number of the pump | ALPHA V EVO |
Country of Origin | Italy |
PumpType | submersible drainage and fecal |
Drive Type | electric |
Installation Type | vertical |
Weight, kg | 17,5 |
Download instructions, catalog for Dreno ALPHA V EVO 3M/G fecal pump with Vortex impeller
